Standard |
IEEE 802.11b/g |
● |
Antenna |
Omni 2dBi Antenna (SMA Connector) |
● |
Frequency Range |
2.400GHz~2.4835GHz |
● |
Operating Frequency/Channel |
2.412~2.462GHz(Canada, FCC)/11 Channels 2.412~2.4842GHz(Japan, TELEC)/14 Channels 2.412~2.472GHz(Euro, ETSI)/13 Channels |
● |
Modulation Technique |
Orthogonal frequency division multiplexing (OFDM) Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK) |
● |
Security |
64/128bit WEP, WPA, WPA2, 802.1x and 802.11i |
● |
Media Access Protocol |
CSMA/CA (Collision Avoidance) with ACK |
● |
Output Power |
11g : 14dBm (Max.) 11b : 17dBm (Max.) |
● |
Data Rate |
11g : 54, 48, 36, 24, 18, 12, 9, and 6Mbps with auto-race fall back 11b : 11, 5.5, 2 and 1Mbps with auto-race fall back |
● |
Sensitivity |
54Mbps:-68dBm 11Mbps:-80dBm |
● |
Working Mode |
Ad-Hoc or Infrastructure |
● |
Throughput |
22Mbps@54Mbps; 5.5Mbps@11Mbps |
● |
Coverage Area |
30~280 meters depends on surroundings |
● |
Operation Temperature |
0~55℃ ambient temperature |
● |
Storage Temperature |
-20~70℃ ambient temperature |
● |
Humidity |
5%~90% |
● |
Power Requirement |
12V 1A |
