Panel
|
Size
|
20.1 inch (Diagonal 510.54mm)
|
Resolution
|
1,440* 1050 / SXGA+
|
Display Color
|
16.2M colors supported
|
Pixel Pitch
|
Horizontal 0.2916mm * Vertical 0.2916mm
|
Brightness
|
300 cd/m2
|
Contrast Ratio
|
600 : 1
|
Viewing Angle [max]
|
Horizontal 150o * Vertical 130o
|
Display Area
|
Horizontal 408.24mm * Vertical 306.18mm
|
Input
|
Signal Input
|
Video Signal : 0.7Vpp
,
75Ω (Separate Synchronization and Composite Synchronization)
|
Sync. Frequency
|
Horizontal 30kHz~82kHz * Vertical 56Hz~76Hz
|
Bandwidth
|
140MHz
|
Input Connector
|
D-Sub/DVI-D
|
Audio
|
Phone Jack, d=3.5mm
|
DC Adaptor
|
AC100~240Volts, 50 ~ 60 Hz
|
Power Consumption (Operation Mode)
|
< 55W
|
Power Consumption (Saving Mode)
|
< 1W
|
Enviornment Requirement
|
Temperature
|
5
℃
~ 35
℃
(Working) / -20
℃
~ 55
℃
(Storage)
|
Humidty
|
20% ~ 80% (Working) / 20%~ 85%(Storage)
|
Dimension [W*H*D]
|
467.0mm*421.0mm*224mm
|
Net Weight
|
5.6kg
|
