General Radio |
|
Bluetooth Class II: 10 meters (in open space) |
|
Carruer Frequency: 2.4 ~ 2.483GHz |
|
Data Rate: Up to 3Mbps |
|
(The maximum operating range depends on the
environmental factors.) |
| ● |
Bluetooth Standard |
|
Bluetooth v2.0 + EDR |
| ● |
Spread Spectrum |
|
FHSS (Frequency Hopping Spread Spectrum) |
| ● |
Modulation Method |
|
GFSK(1Mbps), II/4 DQPSK(2Mbps), 8DPSK(3Mbps) |
| ● |
I/O Interface |
|
USB version 2.0 |
| ● |
Input Power |
|
DV 5V (USB Power) |
| ● |
Sensitivity |
|
-82 dBm (typical), GFSK |
| ● |
RF Output Power |
|
0 dBm (typical), GFSK |
| ● |
System Support |
|
Windows VISTA/XP/2000/ME/98SE |
| ● |
Dimensions |
|
19.4 * 12.1 * 5.5 mm |
| ● |
LED Indicator |
|
Single LED |
| ● |
Bundled Bluetooth Software |
|
IVT BlueSoleil |
| ● |
Advantage Functions |
|
Serial Port Profile |
|
Dial Up Networking Profile |
|
File Transfer Profile |
|
Human Interface Device Profile |
|
Hardcopy Cable Replacement Profile |
|
Headset Profile |
|
Object Push Profile |
|
Synchronization Profile |
|
LAN Access Profile (only available in Windows) |
| ● |
FAX Profile (only available in Windows) |
| ● |
Personal Area Networking Profile
(only available in Windows) |
| ● |
Advanced Audio Distribution Profile
(only available in Windows) |
| ● |
Audio Video Remote Control Profile
(only available in Windows) |
| ● |
Basic Imaging Profile
(only available in Windows) |
