OPERATIONAL

Light Source:

635 nm visible red LED

Optical System:

1500 pixels CCD

Depth of Field:

0-50 mm (PCS 90% code 39)

Resolution:

0.1mm (4 mil)

Scan Rate:

200 Scans/sec

Scanning Width:

Up to 80mm

System Interfaces:

Keyboard, RS-232C, HID USB

PHYSICAL

Cable:

Replaceable, standard 1.8M straight

POWER

Input Voltage:

5 VDC ±5%

Operating Current:

100-120mA typical
