IEEE802.3 10Base-T / 100Base-TX / 1000Base-T
- Ports:8 10/100/1000Mbps Ethernet ports
- Transmission Rates:
- 10Mbps:14880pps
- 100Mbps:148800pps
- 1000Mbps: 1488000pps
- Supported cables:
- 10Base-T: cat 3,4,5 UTP or STP cable (Max Distance 100m)
- 100Base-TX: UTP cat 5, 5e cable (Max Distance 100m)
- 1000Base-TX: UTP cat 5e, 6 cable (Max Distance 100m)
- 8K entry MAC address table
- MDI/MDIX enabled,auto detect pass-through and crossover cable.
- Power Supply:9VDC, 850mA
- Working Temperature: 0°C~40°C
- Humidity: 10%~90%
|
