OPERATIONAL
|
|
Light Source
|
650 nm visible laser diode (VLD)
|
|
Depth of Field
|
0 – 200 mm (UPC/EAN 100%, PCS=90%)
|
|
Scan Pattern
|
5 directions of scan field
|
|
Scan Rate
|
1,400 scans per second (omnidirectional);
|
|
74 scans per second (single-line)
|
|
Number of Scan Lines
|
20
|
|
Minimum Bar Width
|
5 mil @ PCS=90%
|
|
Print Contrast
|
30% @ UPC/EAN 100%
|
|
Indicators (LED)
|
Two-color LED (blue & red)
|
|
Beeper Operation
|
Programmable tone & volume
|
|
System Interfaces
|
Keyboard wedge, RS-232, HID USB, wand emulation
|
|
PHYSICAL
|
|
Dimensions
|
(H)110.9 × (D)65.8 × (W)70.0 mm (on fixed stand);
|
|
Weight
|
200 g (on fixed stand); 350 g (on 3D turning cradle)
|
|
Cable
|
Standard 2.0M straight
|
(H)122.2–253.0 × (D)120.3–163.3 × (W)74.0 mm
(on 3D turning cradle)
|
|
POWER
|
|
Input Voltage
|
5 VDC ±10%
|
|
Power Consumption
|
1.0 watts
|
|
Operating Current
|
200 mA typical
|
|
REGULATORY
|
|
Laser Class
|
CDRH Class IIa; IEC 60825 Class 2
|
|
EMC
|
CE & FCC DOC compliance, VCCI, BSMI
|
|
ENVIRONMENTAL
|
|
Operating Temperature
|
0°C – 40°C (32°F – 104°F)
|
|
Storage Temperature
|
-20°C – 60°C (-4°F – 140°F)
|
|
Humidity
|
5% – 95% RH (no dewing allowed)
|
|
Light Levels
|
Up to 4,500 Lux (fluorescence)
|
|
Drop Durability
|
Designed to withstand 1.5M drops
|
|
|
|
|
* Product availability and specifications depend on territory market strategy; all are subjects to change without prior notice.
|
