Specification Sheet:

Mechanical Spec
Camera Dimension	52.5x22.0x26.0 mm (WxHxD)
Clamp Dimension	32.0x23.4x24.5 mm (WxHxD)
Snapshot function	Yes
LED Indicator	Yes
Cable Length	USB 1.1, 50 cm
Microphone	Yes
Optical Spec.
Lens Focus #	5.0 mm
Distortion	< -3.5 %
Field of Angle	520 ± 20
Focus Type	Manual focus
Focus Distance	4 cm to infinity
Image Sensor	300K Pixel CMOS Sensor
Sensor Size	1/4”
Effective pixels	Up to 640x480
Exposure Control	Auto
White Balance	Initial Automatic Control
Sensitivity	10 Lux
Video & Still Image Resolution
Video Resolution	SVGA: 800X600(RGB 24) must install DirectX 9.0 VGA:  640X480 CIF:  352X288 SIF:  320X240 QCIF: 176X144 QSIF: 160X120
Still Image Resolution	160X120 pixels 176X144 pixels 320X240 pixels 352X288 pixels 640X480 pixels 800X600 pixels 1024X768 pixels 1240X960 pixels
Frame Rate	Up to 30 FPS for VGA mode Up to 30 FPS for CIF mode
Video Format	RGB 24 bits true color I420 compression mode
Power Consumption-During Operation	< 100 mA
Power Consumption-During Standby	< 500 μA



Minimum System Requirements:

OS	System Requirement
PC	l       Intel Pentium III 800MHz MMX compatible PC or faster l       Microsoft Windows 98 SE, ME, 2000 & XP l       64MB RAM (128MB or higher recommended) l       CD-ROM drive l       One available USB 1.1 or 2.0 port l       160MB free hard disk space (260MB recommended) l       Modem, microphone & internet access for internet video messenger l       DirectX 8.0 later



Support Platform:

 Windows XP

 Window 98SE
