| Specification Sheet: |
|
|
|
| Mechanical Spec |
| Camera Dimension |
52.5x22.0x26.0 mm (WxHxD) |
| Clamp Dimension |
32.0x23.4x24.5 mm (WxHxD) |
| Snapshot function |
Yes |
| LED Indicator |
Yes |
| Cable Length |
USB 1.1, 50 cm |
| Microphone |
Yes |
| Optical Spec. |
| Lens Focus # |
5.0 mm |
| Distortion |
< -3.5 % |
| Field of Angle |
520 ± 20 |
| Focus Type |
Manual focus |
| Focus Distance |
4 cm to infinity |
| Image Sensor |
300K Pixel CMOS Sensor |
| Sensor Size |
1/4” |
| Effective pixels |
Up to 640x480 |
| Exposure Control |
Auto |
| White Balance |
Initial Automatic Control |
| Sensitivity |
10 Lux |
| Video & Still Image Resolution |
| Video Resolution |
SVGA: 800X600(RGB 24) must install DirectX 9.0 |
| VGA: 640X480 |
| CIF: 352X288 |
| SIF: 320X240 |
| QCIF: 176X144 |
| QSIF: 160X120 |
| Still Image Resolution |
160X120 pixels |
| 176X144 pixels |
| 320X240 pixels |
| 352X288 pixels |
| 640X480 pixels |
| 800X600 pixels |
| 1024X768 pixels |
| 1240X960 pixels |
| Frame Rate |
Up to 30 FPS for VGA mode |
| Up to 30 FPS for CIF mode |
| Video Format |
RGB 24 bits true color |
| I420 compression mode |
| Power Consumption-During Operation |
< 100 mA |
| Power Consumption-During Standby |
< 500 μA |
|
|
| Minimum System Requirements: |
|
|
| OS |
System Requirement |
| PC |
Intel Pentium III 800MHz MMX compatible PC or faster |
| Microsoft Windows 98 SE, ME, 2000 & XP |
| 64MB RAM (128MB or higher recommended) |
| CD-ROM drive |
| One available USB 1.1 or 2.0 port |
| 160MB free hard disk space (260MB recommended) |
| Modem, microphone & internet access for internet video messenger |
| DirectX 8.0 later |
|
|
| Support Platform: |
|
|
|
| Windows XP |
|
| Windows 2000 |
|
| Windows ME |
|
| Window 98SE |
|
