ear47mtete|2010274B9681|kaiomy|Product|Spec|0xfdffb209000000000402000001000100  Network Standards: IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
Protocol: CSMA/CD
Topology: Star
Ports: 8
Switching Mechanism: Store-and-Forward
Transmission Rates: 10Mbps: 14880pps, 100Mbps: 148800pps
On-chip 1024-entry look-up table in direct mapping mode
Flow Control: IEEE802.3x full-duplex flow control and half-duplex
backpressure flow control
MDI/MDIX enabled, auto detect pass-through and crossover cable
Port priority function is enabled on 8th port, all ingress packets from
port8 will be considered as high priority, which will be benefit for
VOIP packets transmission regarding time delay problem
Supported cables: 10Base-T: cat 3,4,5 UTP or STP cable, Max
Distance 100 meters; 100Base-TX: cat5 STP or UTP cable, Maxim
Distance 100 meters
Power Supply: 5V/600mA Adapter
Working Temperature: -20℃~50℃
Humidity: 10%~90% |
